Applications:
Such series are mainly used to extrude steel cutting, cast iron filling, copper scrap and aluminum scrap into high denisty cylinder bulk, in order to achieve convenient reclamation and easy refining, especially, the extruded casting iron filling may substitute foundry iron.
①Hydraulic drive, stable operation, vibration-free, safety and reliability
②Requires simple equipment foundation
③Adops PLC automatic control and the users can select manual or automatic operation.
| No. | Model | Nominal Force | Briquette Size(D×H) | Pressure on The bale | Power | Capactiy |
|---|---|---|---|---|---|---|
| 1 | Y83-250 | 2500kN/250t | ?110×180mm | 263Mpa | 18.5kW |
800-1200kg/h Cast iron sawdust |
| 2 | Y83-315 | 3150kN/315t | ?120×180mm | 278Mpa | 22kW | |
| 3 | Y83-400 | 4000kN/400t | ?140×300mm | 260Mpa | 30/37kW | |
| 4 | Y83-500 | 5000kN/500t | ?150×300mm | 283Mpa | 45kW |
1200-1500kg/h Cast iron sawdust |
| ?180×300mm | 196Mpa | |||||
| 5 | Y83-630 | 6300kN/630t | ?200×300mm | 220Mpa | 55kW |
1800-2000kg/h Cast iron sawdust |
| 6 | Y83-1000W | 10000kN/1000t | ?250×200mm | 230Mpa | 45kW×4 |
8000-12000kg/h Cast iron sawdust |
